Premium Tree Pool Cover with Durable Steel Grating Design

Image Grand : Premium Tree Pool Cover with Durable Steel Grating Design

Détails sur le produit:

Lieu d'origine:	CHINE
Nom de marque:	GNEE
Certification:	SGS

Conditions de paiement et expédition:

Quantité de commande min:	10 mètres carrés
Prix:	negotiable
Détails d'emballage:	Emballage digne de la mer, c'est-à-dire un plateau en bois ou en acier avec bande d'acier, e
Délai de livraison:	5-9 jours ouvrables
Conditions de paiement:	Négociable
Capacité d'approvisionnement:	100 tonnes / semaine

Contact

Premium Tree Pool Cover with Durable Steel Grating Design

description de

Mettre en évidence:

stainless steel grating pool cover

durable tree pool cover

premium steel grating cover

Special shaped steel grating is based on the actual needs of customers to produce a variety of irregular shape of steel grating. Special shaped steel grating has anti-slip surface, high load bearing capacity, corrosion resistance. So it widely used as well covers, industry operating platform of factory and floors of fountain.

Stainless steel grating is regarded as industrial grade bar grating, which is extremely strong, durable and corrosive resistant for all load bearing applications and is primarily used for pedestrian and light vehicle traffic.Two production methods:

Premium Tree Pool Cover with Durable Steel Grating Design 0

Product Name
Material	Mild Steel(Low Carbon Steel),S235,S275JR,A36,or Stainless Steel SS304,SS316 etc, Alumium 3003, 5052
Surface treatment	Hot dipped galvanized polished or untreated
Bearing bar (width x thickness)	25x3,25x4,30x3,30x4,30x5,32x5,40x5,50x5,75x10mm
Bearing bar pitch	12.5,15,20,23.85,25,30,30.16,30.3,34.3,35,40,41,60mm.
	US standard:1"x3/16",11/4"x3/16",11/2"x3/16",1"x 1/4",
	11/4"×1/4",11/2"x 1/4"etc.
Cross bar pitch	38,50,76,100,101.6mm or customized
Pitch of Bearing bar	Cross-bar Pitch	Specification of bearing bar(widthxthickness)
		20×3	25×3	32×3	40×3	20×5	25×5
30	100	G203/30/100	G253/30/100	G323/30/100	G403/30/100	G205/30/100	G255/30/100
30	50	G203/30/50	G253/30/50	G323/30/50	G403/30/50	G205/30/50	G255/30/50
40	100	G203/40/100	G253/40/100	G323/40/100	G403/40/100	G205/40/100	G255/40/100
40	50	G203/40/50	G253/40/50	G323/40/50	G403/40/50	G205/40/50	G255/40/50
60	50		G253/60/50	G253/60/50	G403/60/50	G205/60/50	G255/60/50
Pitch of Bearing bar	Cross-bar Pitch	Specification of bearing bar(widthxthickness)
		32×5	40×5	45×5	50×5	55×5	60×5
30	100	G325/30/100	G405/30/100	G455/30/100	G505/30/100	G555/30/100	G605/30/100
30	50	G325/30/50	G405/30/50	G455/30/50	G505/30/50	G555/30/50	G605/30/50
40	100	G325/40/100	G405/40/100	G455/40/100	G505/40/100	G555/40/100	G605/40/100
40	50	G325/40/50	G405/40/50	G455/40/50	G505/40/50	G555/40/50	G605/40/50
60	50	G325/60/50	G405/60/50	G455/60/50	G505/60/50	G555/60/50	G605/60/50
Application	Working Platform, Handrail Infill, Walkway, Bridge decking, Stair Treads, Transformer Reservoir,Trench Cover, Ceiling, Grating Fence Sunshade Panels

Premium Tree Pool Cover with Durable Steel Grating Design 1
